220V AC Encapsulated Solenoid Valve 2K Series Coil Grommet

$9.43

WIC Valve 2K Series 220V AC Encapsulated Solenoid Valve Coil Class H IP 65 Continuous Duty Coil, Long Life Cycle, Great Price



In stock

SKU: 2K-220VAC-G Category:
Wisdom International Corporation WIC Valve
Wisdom International Corporation WIC Valve

Description

WIC Valve 2K Series 220/240V AC Encapsulated Solenoid Valve Coil with Lead Wire



2K Series Solenoid Valve Coil Specification:

Model Number: 2K-220VAC-G

Coil Power: 6.5VA

Coil Class: IP 65 (CE Certification)

Coil Duty: 100% ED (Continuous Duty)

Coil Voltage: 220/240V AC

Electrical Connection: Grommet with Lead Wire



WIC Valve 2K Series Solenoid Valve Coil Dimensions (Unit=mm):

2K Electric Solenoid Valve Coil Dimension

What is IP65?

Ingress Protection (IP) ratings are developed by the European Committee for Electro Technical Standardization (CENELEC) (NEMA IEC 60529 Degrees of Protection Provided by Enclosures – IP Code), specifying the environmental protection the enclosure provides.

The IP rating normally has two (or three) numbers:

1) Protection from solid objects or materials

2) Protection from liquids (water)

3) Protection against mechanical impacts (commonly omitted, the third number is not a part of IEC 60529)

IP First number – Protection against solid objects

0 No special protection
1 Protected against solid objects over 50 mm, e.g. accidental touch by persons hands.
2 Protected against solid objects over 12 mm, e.g. persons fingers.
3 Protected against solid objects over 2.5 mm (tools and wires).
4 Protected against solid objects over 1 mm (tools, wires, and small wires).
5 Protected against dust limited ingress (no harmful deposit).
6 Totally protected against dust.

IP Second number – Protection against liquids

0 No protection.
1 Protection against vertically falling drops of water e.g. condensation.
2 Protection against direct sprays of water up to 15o from the vertical.
3 Protected against direct sprays of water up to 60o from the vertical.
4 Protection against water sprayed from all directions – limited ingress permitted.
5 Protected against low pressure jets of water from all directions – limited ingress.
6 Protected against temporary flooding of water, e.g. for use on ship decks – limited ingress permitted.
7 Protected against the effect of immersion between 15 cm and 1 m.
8 Protects against long periods of immersion under pressure.

Additional information

Weight 0.60 lbs
Dimensions 1.00 × 1.00 × 1.00 in
